This article introduces the setting method of "Macro PDF transmission/decoding mode symbol", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set Macro PDF transmission/decoding mode symbols?
- Where is the Macro PDF transmission/decoding mode symbol configuration barcode?
- How to adjust the symbol parameters of Macro PDF transmission/decoding mode?
Resolution / Answer
This article introduces the use and configuration method of "Macro PDF transmission/decoding mode symbols". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
- **Buffer all symbols / Transmit Macro PDF when complete**: Transmit all decoded data only after the entire sequence has been scanned and decoded. When using this mode, it is recommended to use the buzzer and LED signals provided by PL3307 at the same time to ensure user feedback. If the decoded data exceeds the upper limit of 50 symbols, it will not be transmitted (because the sequence has not been completely scanned). You can clear the buffer using "Clearing the Macro Buffer" on page 11-91.
- **Transfer any symbols in the set in any order**: Transmit each Macro PDF symbol decoded (while still doing some error handling, see Table 11-6). Selecting this mode should also enable "Transfer Macro PDF Control Head" on page 11-90 and use buzzer and LED signals for user feedback.
- **Transmit all symbols**: Transmit and decode all Macro PDF symbols without subsequent processing. In this mode, the host is responsible for detecting and parsing Macro PDF sequences.
This mode should be used if the decoder's BEEPER_ON signal is not used to drive a buzzer (see Table 2-3 on page 2-10 and Table 3-3 on page 3-10). Certain scan sequences in other modes are only fed back via audio, without any user feedback when BEEPER_ON is not connected. All actions marked "Do not transmit" in Table 11-6 rely on BEEPER_ON for feedback; when using the "Transparent All Symbols" mode, each decoding is transmitted to the host, and the host software provides appropriate feedback.
Buffer all symbols / transfer Macro PDF when complete (00h)
Scan the following barcode, buffer all symbols/transmit Macro PDF (00h) when complete.
Transmit any symbol in the set in any order (01h)
Scan the following barcode to transmit any symbol (01h) in the set in any order.
* Transparently transmit all symbols (04h)
Scan the following barcode to *transmit all symbols (04h).
