This article introduces the setting method of "Transfer Macro PDF Control Head", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
CS9501, E950, RS-9000BT, RS-9000PT, RF5520, RF5520U
Questions
- How to set up the transfer Macro PDF control header?
- Where is the control header configuration barcode for transferring Macro PDF?
- How to adjust the parameters of the control head when transmitting Macro PDF?
Resolution / Answer
This article introduces the purpose and configuration method of "Transfer Macro PDF Control Header". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
When enabled, the control header of the Macro PDF symbol (containing the segment index and file ID) is transmitted. For example: `\92800000\725\120\343`. The 5 digits after `\928` are the segment index (block index), and `\725\120\343` is the file ID.
Enabled when "Transfer any symbols in collection in any order" mode on page 11-89 is selected; disabled when "Buffer all symbols/Transfer Macro PDF on complete" mode is selected. This parameter is invalid when "Transparent All Symbols" mode is selected.
Enable Macro PDF control header transmission (01h)
Scan the following barcode to enable Macro PDF control header transmission (01h).
* Disable Macro PDF control header transmission (00h)
Scan the following barcode, * Disable Macro PDF Control Header Transmission (00h).
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
