This article introduces the setting method of "self-sensing", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
C740, E740, F1900, F20, K6, L3, L6BL, L3S, L6BLS, L6S, NT-2100, R3L, S3, S6, H3, M20, NT-1228BC, W6, W6-X, Z3S
Questions
- How to set up auto-sensing?
- Where is the self-sensing configuration barcode?
- How to adjust the self-sensing parameters?
Resolution / Answer
This setting controls when the device starts scanning, how long it lasts, and how continuous scans are handled. It is usually adjusted when manual triggering, automatic sensing, avoiding repeated output or improving scanning response speed are required.
Turn off IR auto-sensing*
Scan the following barcode to turn off IR auto-sensing*.
Turn on IR automatic sensing
Scan the following barcode to enable IR automatic sensing.
0265 + Sensitivity setting (0x01~0xFF), interval setting (0x01~0x40)
Scan the following barcode to configure 0265 + sensitivity setting (0x01~0xFF), interval setting (0x01~0x40).
0x77 represents the sensitivity. The smaller the value, the higher the sensitivity. 0x05 represents the interval of 500ms.
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
