This article introduces the setting method of "Decoding Successful LED Light Duration", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set the decoding success LED light duration?
- Where is the LED light duration configuration barcode after successful decoding?
- How to adjust the LED light duration parameters after successful decoding?
Resolution / Answer
This article introduces the use and configuration method of "Decoding Success LED Light Duration". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
Quick settings of 20ms, 120ms, 220ms, and 320ms are available.
**[Short (20ms)]
Scan the following barcode to configure **[short (20ms)].
[Medium (120ms)]
Scan the following barcode to configure [Medium (120ms)].
[Long (220ms)]
Scan the following barcode to configure [Length (220ms)].
[Features (320ms)]
Scan the following barcode to configure [Features (320ms)].
[Decoding successful LED light duration custom setting
Scan the following barcode to configure [Decoding successful LED light duration customization settings.
(Range 1-2500ms)]
Set the decoding success LED light duration to 800ms, which can be set by reading the following barcodes in sequence:
- Read "Startup Settings"
- Read "Decoding successful LED light duration custom setting"
- Data code "8", "0", "0" (see Appendix - Data Code)
- Read "Save" (see Appendix - Save or Cancel)
- Read "Exit Settings"
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
