This article introduces the setting method of "successful decoding sound duration", which is suitable for finding the corresponding configuration barcode and completing parameter adjustment.
Applicable to:
E900
Questions
- How to set the duration of successful decoding sound?
- Where is the sound duration configuration barcode for successful decoding?
- How to adjust the duration parameters of the successfully decoded sound?
Resolution / Answer
This article introduces the use and configuration method of "Decoding Successful Sound Duration". Usually refer to this article when you need to change the default behavior of the device, adapt to the business system, or find the corresponding configuration barcode.
You can choose quick settings of 40ms, 80ms, and 120ms.
[Short (40ms)]
Scan the following barcode to configure [short (40ms)].
**[Medium(80ms)]
Scan the following barcode to configure **[Medium (80ms)].
[Long (120ms)]
Scan the following barcode to configure [Length (120ms)].
IIl
[Decoding successful sound duration custom settings
(Range 20-300ms)]
Set the duration of the successful decoding sound to 200ms. You can set it by reading the following barcodes in sequence:
- Read "Startup Settings"
- Read "Decoding successful sound duration custom setting (range 20-300ms)"
- Data code "2", "0", "0" (see Appendix - Data Code)
- Read "Save" (see Appendix - Save or Cancel)
- Read "Exit Settings"
If this does not resolve the issue, please reset the barcode scanner or contact us. Click here to find your barcode scanner model and perform the reset.
